Upper blade holder clamps and tensions blade in one step (Patent Pending)
Removable lower blade holder snaps quickly and securely in to place
Large 12-7/8" x 23" cast iron table provides a stable working surface while also limiting vibration
Slotted table for easier and quicker blade changes
22" throat capacity
Arm tilts 45° right and 40° left, keeping the work table flat for more accurate cutting
Integrated blade storage features slots for pre-loaded blades and a built-in wrench for changing blades
Blade storage can be positioned on the right or left of the machine
Top lift, spring loaded arm raises 10" and stays up until pulled back down
Removable dust port on underside of table to collect dust at the source
Stand can be adjusted to 4 different heights - 24-3/4", 26-3/4", 28-3/4" or 31-3/4" (using the leveling feet)
Variable speed range of 400 - 1550 strokes per minute
2" maximum cutting depth
Conveniently located speed and tension controls
Included equipment: Material hold down, Onboard Dust Blower, Foot Switch, Stand
Table material: Cast Iron
Stroke length: 3/4"
Tilting function: Arm
Blade tilt range: 45° R, 40° L
Maximum cutting depth: 2"
Speed range (Stroke/min): 400 - 1550
Table size (L x W): 12-2/3" x 23-5/8"
Motor voltage (V): 120
Motor amps: 1.3
Table height: 32" to 38"
Assembled machine dimensions (L x W x H): 33" x 25-1/2" x 48"
Net weight (Lbs.): 89.7
