CSC Cordless Table Saw CSC SYS 50 EBI-BASIC / Bare Saw

CSC Cordless Table Saw CSC SYS 50 EBI-BASIC / Bare Saw

The ultimate in portable precision. The cordless table saw that fits in a Systainer.

The CSC SYS 50 cordless table saw is so compact that it fits into a Systainer. It's just as versatile in use, as it is tremendously convenient in its size. Make rip cuts of up to 11" (280 mm), cross-cut widths of up to 17-3/4" (450 mm) and bevel cuts of -2° to 47°. The unique digital operation produces results with maximum precision, with accuracy within a tenth of a millimeter (1/256"). The 2x18 V dual battery system in combination with the brushless EC-TEC motor will impress you with its power and torque – you won't notice any difference compared with a corded tablesaw. Together with the UG-CSC-SYS underframe, you have the perfect worktable with built-in support for ripping and cross-cutting, and it collapses for easy transport from the vehicle to the site. The CSC SYS 50: The ultimate in portable precision.

Main applications

• Cross-cuts up to 17-3/4" (450 mm) wide, quick and precise with the integrated slide
• Rip cutting up to a cutting height of 1-7/8" (48 mm) and a width of 11" (280 mm) with a secure support on the integrated fold-out table
• Bevel cuts from -2° to 47° (-10° possible in the event of a restricted cutting depth of 13/16" - 1-1/4" (21–32 mm) thanks to the tilting saw blade
• Exact height and angle adjustment by means of electric stepper motors. Can be set precisely to 0.1 mm (1/256") and controllable via a display
• Transport easily in the integrated Systainer format

Specifications

Battery voltage

2 x 18 V

No-load speed

4 500 – 6 800 RPM

Inclination angle

-10 - +47 °

Mitre angle

0 - 70 °

Drive type

Battery

Weight

33.08 lbs (15 kg)

Dust extraction connection dia.

1-1/16" (27 mm)

Dimensions (L x W x H)

20-5/32" x 15-19/32" x 11-21/32" (512 x 396 x 296 mm)

Cutting depth 45°

0 - 1-11/32" (0 - 34 mm)

Cutting height 0°

0 - 1-7/8" (0 - 48 mm)

Saw blade location hole

3/4" (20 mm)

Parallel cut width

11" (280 mm)

Tabletop height

11" (228 mm)

Cutting height -10°

13-16" - 1-1/4" (21 - 32 mm)
