Description
Powermatic 1285T 12" Parallelogram Jointer 1Ph 230v Armorglide
Now featuring ArmorGlide Technology that is low-friction and rust-resistant, the Powermatic 1285T 12-inch Jointer offers big capacity and performance in a machine that is loaded with features. A large center-mounted fence assembly adjusts easily by a rack and pinion system with ram lock. Preset stops on the fence body allow for fast angle set-up at 45° in and out, and a positive stop for perfect 90° angles. The parallelogram design keeps the table in close proximity to the cutterhead for improved finish and allows for a fast depth of cut adjustment. This design also ensures the tables remain perfectly parallel even after years of tough duty. This model features a straight knife cutterhead.
Features
- ArmorGlide Technology gives you a low-friction, industrial-grade coating on the work surface that is rust-resistant, requires less maintenance, and gives you more control
- Large 12" x 84" precision-ground cast iron table surface for heavy-duty work
- Parallelogram design ensures close table-to-cutterhead proximity and fast depth of cut adjustments
- Rack and pinion adjustable cast iron fence assembly allows for smooth fence positioning without play
- Straight knife cutterhead with three high-speed steel knives create a clean cut
- Table "lips" on both sides of cutterhead aid in noise reduction
NOTE: The recommended max cutting depth for non-rabbeting cuts is 1/8”. The max cutting depth for rabbeting cuts is 1/2" as the manual has always stated.
Specifications
Stock Number | PM1-1791241T |
Cuts Per Minute | 15,000 |
Cutterhead Speed (RPM) | 5000.0000 |
Cutting Capacity (W x D) (In.) | 11-3/4 x 3/4 |
Dust Collection Minimum CFM Required (CFM) | 800 |
Dust Port Outside Diameter (In.) | 4 |
Model Number | 1285T |
Motor Power (HP) | 3 |
Motor Voltage (V.) | 230 |
Number of Knives | 3 |
Prewired Voltage (V.) | 230 |
Max.Rabbeting Capacity (In.) | 3/4" |
Recommended Circuit Size (Amps.) | 30 |
Type of Cutterhead | Straight Knife |
Maximum Cutting Depth (In.) | 1/8" |
