4375 Wide Belt Sander 10HP 1PH

Offering woodworkers a maximum sanding width 43", and available in single or three phase power, this American Made Wide Belt Sander will likely outlive you. Don't take our word for it! Jeff Roltgen of Roltgen Woodworks, had the following to say "Even the fussiest of finishes only need a cursory random orbit sanding after coming out of this machine."

10 Hp, Single Phase (1~), 220 Volt

This single drum, 43" Wide Belt Sander features a 75" belt, providing 25% more abrasive surface than the smaller 60" belt machines. The larger belt translates to increased capacity, less heat accumulation, less maintenance and fewer belt replacements. With a fully adjustable platen these sanders will deliver a perfect smooth finish every time.

Standard Equipment

• Photo electric belt tracking
• Pneumatic belt tension
• 2-1/2" graphite covered felt pad and adjustable platen
• 2 rubber-covered pinch rollers 2-1/2 OD
• 2 machined idler rollers 4-1/4" OD with 1" bearings
• Rubber-covered contact roller 5-1/4" OD with 1-5/8" drive bearing
• Conveyor table set on four 1" acme thread jackscrews
• 2 height adjustment indicators
• 6" internal dust chute
• 5 emergency stops
• 3 year warranty

Additional Information

• Weight: 2389 lbs
• Dimensions: 60" x 62" x 71"
• Max. working length: Unlimited
• Min. working length: 12"/305mm
• Main motor: 10 Hp, Single Phase (1~), 220 Volt
• Max. working width: 42"/1070mm
• Max. working thickness: 7-1/4"/184mm
• Min. working thickness: 1/8"/3mm
• Vacuum requirement: 1000 CFM
• Conveyor speed: 0-18 FPM
• Durometer of contact roller: 60
• Sanding belt size: 43" x 75"
